HIGH PERFORMANCE PURE AUDIO CABLE OYAIDE NEO d+ Series
Line up
| TYPE | MODEL | LENGTH | PRICE | ORDER |
|---|---|---|---|---|
| OYAIDE NEO d+ FireWire 6pin-6pin (FireWire400)-(FireWire400) |
OYAIDE NEO d+ FW6x6 1.0m | 1.0m | US$99.00 |  |
| OYAIDE NEO d+ FW6x6 2.0m | 2.0m | US$119.00 | |
|
| OYAIDE NEO d+ FireWire 6pin-9pin (FireWire400)-(FireWire800) |
OYAIDE NEO d+ FW6x9 1.0m | 1.0m | US$99.00 | |
| OYAIDE NEO d+ FW6x9 2.0m | 2.0m | US$119.00 | This item is currenty out stock. | |
| OYAIDE NEO d+ FireWire 9pin9pin (FireWire800)-(FireWire800) |
OYAIDE NEO d+ FW9x9 1.0m | 1.0m | US$114.00 | |
| OYAIDE NEO d+ FW9x9 2.0m | 2.0m | US$139.00 | |
Most Definitely... OYAIDE NEO d+ evolves transmission of the audio I/O
- OYAIDE NEO d+ FireWire is designed and specialized for FireWire audio interfaces which are used in most sound production. Due to the fact that the amount of the data transmission of sound and visual is massive and complicate, a cable takes important role for real-time data transmission.
- The conductor is made of “Silver-coating OFC (Oxygen-Free Copper)” in order to actualize hi-speed data transmission. And, the combination of double shielding, twist-pair structure, and TPE outer sheath protects signals from the external noise contamination and electro-magnetic interference.
- In addition, its impedance is carefully adjusted for accurate data transmission. Due to these factors, OYAIDE NEO d+ series realizes dynamic and hi-definition sound liberated from planar sound image which is more likely to digital sound.
- For all music people such as producers, musicians, sound engineers, sound designers and listeners, “OYAIDE NEO d+ Firewire” provides hi-performance for the next level of sound production.
- In order to make sure high-performance serial bus, “Silver-coating OFC (Oxygen-Free Copper)” is employed for its conductor material. By coating silver which has about 5% lower resistance than copper has and its skin effect, it actualize hi-speed transmission and doesn’ t lose sound details and dynamics.
- The impedance matching is calibrated by exact pitches for accurate data transmission and excellent stability.
- The combination of double shielding, twist-pair structure, and TPE outer sheath protects signals from the external noise contamination and electro-magnetic interference.
- In order to enhance the hi-speed transmission property, Foam-PE is employed for its insulator due to excellent electric insulation property and low dielectric ratio.
- By 24K gold plated bronze alloy contacts, it maintains durability and transmission stability for a long time.
- The body of the connectors made of 30% glass filled PBT and aluminum outer cover are employed for hi-speed vibration attenuation property. And this will help to stabilize the clock operation at bus-powered for lossless sound recording and playing.
FEATURES
| OYAIDE NEO d+ FireWire series SPEC | |
|---|---|
| Cable | IEEE1394a (FireWire/i.Link) |
| Transfer speed | Maximum 400Mbps |
| Bandwidth | FireWire (IEEE 1394) 100 / 98.304 Mbit/s |
| FireWire (IEEE 1394) 200 / 196.608 Mbit/s | |
| FireWire (IEEE 1394) 400 / 393.216 Mbit/s | |
| Conductor | Silver plated OFC (Oxygen Free Copper) |
| Structure | twist-pair + Inverted concentric structure) |
| Shield | Separated double shield（tin plated wire + aluminum tape） |
| Insulator | Foam Polyethylene |
| Sheath | Thermoplastic Elastomers |
| Connector | IEEE1394 6pin connector（Type A) & IEEE1394 9pin connector（Type B) |
| Terminals | 24K gold plated bronze alloy |
| Body | PBT + Glass Fiber30% |
| Outer cover | Aluminum |
