- Digital Music Data Converter for iPod/iPhone/iPad.
- Fully compatible with 30P Dock connector equipped iPod/iPhone.
- Fully compatible with Brand New Lightnig connector equipped iPod touch 5th, iPod mini 7th, iPhone 5, iPad 4th. and iPad mini.
- Just hook up with Apple Lightning – USB cable or 30P dock connector –USB cable.
- S/PDIF Digital Audio Output, Coaxtial and Toslink/Optical for Audio System.
- Two independent X-tal Audio Master Clock oscillators (22.576MHz and 22.5792MHz) generate precise S/PDIF Digital Audio output signal.
- Low ripple and spike noise powerful AC adapter provides enough power to charge iPod/iPhone/iPad(2nd or newer).
- Ready for Apple Remote, provides same function as iPod Universal Dock.
- Elegant design matches to High-Fidelity Audio System.
Supported Apple Products
- Ready for Lightning iPod touch 5th, iPod mini 7th, iPhone 5 and iPad mini.
- iPhone 4S, iPhone4, iPhone3GS, iPhone3
iPod Touch (1st - 4th generations)
iPod Nano (3rd - 6th generations)
iPod Classic
iPad, iPad2 （The iPod application can be used, but charging is not possible.）
Supported Audio Equipment
- Audio devices equipped with optical or coaxial input terminals.
| Name | iPod digital audio converter |
|---|---|
| Model Number | RAL-1648iP1 |
| Inputs | Standard USB-A |
| Outputs | Digital audio output (S/PDIF) |
| Supported Devices | Ready for Lightning iPod touch 5th, iPod mini 7th, iPhone 5 and iPad mini. |
| Power Supply Voltage | DC +5V (supplied via AC adapter) |
| Current Consumption | When connected to iPhone / iPod: 1.3A (including charging current of 1A) |
| Operating Environment | Temperature: 0 - 55ºC (32 - 131°F), Humidity: 20 - 80% (without condensation) |
| Unit Dimensions/Weight | 108 (W) x 125 (D) x 43 (H) mm (4.2 x 5.0 x 1.7 in.) |
| Supported Audio Devices | Audio devices with digital (coaxial) inputs, audio devices with analog (RCA) inputs, headphones with a standard stereo plug |
| Included Items | RAL-1648iP1unit |
| JAN Code | 4949090920682 |
- Volume cannot be adjusted with the iPod / iPhone. Please adjust the volume on the audio device the product is connected to.
- When using the Apple Remote, refer to the user guide included with that device.
- “Made for iPod” and “Made for iPhone” signify that the electronic accessories are designed specifically for connection to iPod and iPhone, fulfill Apple’s designated performance requirements and are certified by the developer.
- Using this product with iPod or iPhone may affect the wireless functionality of those devices.
- iPhone, iPod Classic, iPod Nano, and iPod touch are registered trademarks of Apple Inc. in the United States of America and other countries.
- The look of the product and some specifications are subject to change without notice. Consumption tax is not included in the listed price.
